TrafficInsights - Top N

Follow

By default, the Top N view shows details for the top 10. To change the view to the top 15 or top 25, click the tab from the top navigation bar.


The default presentation is a summary of the top N. For a larger presentation of the graphs, click the appropriate tabs. Available options are Top Addresses, Top Conversations, Top Autonomous Systems, and Top Ports.

  • For Top Addresses, you see two graphs: one for top source addresses and one for top destination addresses.
  • For Top Conversations, you see one graph.
  • For Top Autonomous Systems, you see three graphs: one for top source autonomous systems, one for top destination autonomous systems, and one for temporal evolution (source destination).
  • For Top Ports, you see two graphs: one for top source ports and one for top destination ports.
